Thread size | M5x0.8mm |
Body material | Stainless steel 304 |
Maximum material thickness in millimeter (G) | 3.3 |
Minimum material thickness in millimeter (G) | 0.500 |
Head type | L |
Head diameter in millimeter (HD) | 10.54 |
Head diameter tolerence in ± millimeter | 0.25 |
External diameter in millimeter (D) | 7.47 |
Diameter tolerence in ± millimeter | 0.050 |
Length of the insert in millimeter (L) | 12.07 |
Length of the insert tolerence in ± millimeter | 0.25 |
Hole / drill required | 7.54mm ( 19/64 ) |
Thickness of the head in millimeter (HH) | 0.71 |
Thickness of the head tolerence in ± millimeter | 0.07 |
Body color | Natural |
