Body color | Black |
External diameter in inches (D) | 0.200 |
Diameter tolerence in ± in inches | 0.004 |
Minimum riveting capacity in inches (G) | 0.020 |
Maximum riveting capacity in inches (G) | 0.067 |
Head diameter in inches (F) | 0.248 |
Head diameter tolerence in ± inches | 0.018 |
Thickness of the head in inches (H) | 0.030 |
Thickness of the head tolerence in ± inches | 0.005 |
Length of the rivet in inches (L) | 0.375 |
Length of the rivet tolerence in ± in inches | 0.015 |
Hole / drill required | 13/64 |
Body material | Nylon |
Mandrel Material | Steel |
Mandrel length approx. in inches | 1.260 |
