Thread size | 0.190 10-24 |
Body material | Steel |
Maximum material thickness in inches (G) | |
Minimum material thickness in inches (G) | 0.062 |
Head type | W |
Head diameter in inches (HD) | 0.320 |
Head diameter tolerence in ± inches | 0.005 |
External diameter in inches (D) | 0.293 |
Diameter tolerence in ± in inches | 0.002 |
Length of the insert in inches (L) | 0.370 |
Length of the insert tolerence in ± inches | 0.015 |
Hole / drill required | 0.297- #19/64 |
Thickness of the head in inches (HH) | |
Thickness of the head tolerence in ± inches | |
Body color | Cadmium matte silver |
