Thread size | M8x1.25 |
Body material | Steel |
Maximum material thickness in millimeter (G) | 3.80 |
Minimum material thickness in millimeter (G) | 0.70 |
Head type | K |
Head diameter in millimeter (HD) | 15.11 |
Head diameter tolerence in ± millimeter | 0.38 |
External diameter in millimeter (D) | 13.42 |
Diameter tolerence in ± millimeter | 0.050 |
Length of the insert in millimeter (L) | 17.53 |
Length of the insert tolerence in ± millimeter | 0.38 |
Hole / drill required | 13.49mm ( 17/32 ) |
Thickness of the head in millimeter (HH) | 0.58 |
Thickness of the head tolerence in ± millimeter | 0.08 |
Body color | Zinc yellow |
