Rivet diameter in inches (D) | 0.250 |
Diameter tolerence in ± in inches | 0.003 |
Maximum riveting capacity in inches (G) | 0.504 |
Body material | Aluminum |
Mandrel Material | Aluminum |
Head type | Dome |
Head diameter in inches (F) | 0.515 |
Head diameter tolerence in ± inches | 0.025 |
Thickness of the head in inches (H) | 0.117 |
Thickness of the head tolerence in ± inches | 0.005 |
Body color | Natural |
Tensile force in lb by rivet | 760 |
Shear strength in lb by rivet | 1100 |
Minimum riveting capacity in inches (G) | 0.425 |
Length of the rivet in inches (L) | 0.748 |
Length of the rivet tolerence in ± in inches | 0.015 |
Hole / drill required | 0.266 - 17/64 |
